Stuttgart  /  November 07, 2023  -  November 10, 2023

Blechexpo 2023

International Trade Fair for sheet metal working

Hall 5, Stand 5505

Joint Stand of EFB - Europäische Forschungsgesellschaft für Blechverarbeitung e.V.

Our Topics:

F-Scanner for coating inspection
© Yanfeng Zhang/Jier North America
F-Scanner 1D with laser protection shield for oil film measurement in the production line of a stamping plant. Both units capture sheet metal blanks of up to four meters in width.

We will be presenting the F-Scanner 1D, a scanning fluorescence inspection system for 100-percent imaging coating and cleanliness detection of 3D parts. For inline measurement, the components, e. g. formed body components, are moved forward on a conveyor belt. Passing the measuring system, the scanner detects the components’ surface point by point. The measurement data is processed in real time and displayed on a monitor as an image. The data provides quantitative information on lubrication, on filmic or particulate contamination, and on the coating quality of the component.
